The Sage Series S55i is an in-wall subwoofer from Wisdom Audio, using four long-throw drivers and Regenerative Transmission Line loading to deliver fast, tuneful low-frequency output from inside the wall. Price on application.
The Sage Series S55i is an in-wall subwoofer from Wisdom Audio, designed to add fast, articulate low-frequency output to a system without any visible box in the room. It uses Wisdom’s Regenerative Transmission Line loading and four long-throw drivers to combine high output with the speed and tonality that make a subwoofer blend seamlessly rather than draw attention to itself.
The S55i is built to mount discreetly and flexibly — in-wall, in-ceiling, under risers, in closets or on the floor — with a paintable grille and bezel so it finishes flush and out of sight. An optional floor/ceiling extension port kit allows it to vent into the room from an adjacent space such as an attic, riser, closet or void, giving the installer real freedom in how and where it is placed.
The S55i is quoted with a response of 40 Hz–80 Hz (±3 dB relative to the target curve), a sensitivity of 90 dB/2.83 V/1 m and a maximum output of 112 dB at 40 Hz/1 m. The Regenerative Transmission Line design is what gives it its combination of quick, tuneful bass and genuine in-room authority from a slim in-wall format.
Four custom-designed high-output long-throw 3 × 5-inch woofers; Regenerative Transmission Line loading; multiple mounting options; paintable grille and bezel; optional floor/ceiling extension port kit. Like the rest of the Sage Series it is an active, processor-driven design requiring Wisdom Audio DSP and one channel of amplification per subwoofer.
Regenerative Transmission Line (RTL) is Wisdom’s proprietary loading technique, developed to yield an unusual combination of high sensitivity, high output and low distortion with uniform, extended response. Driven by Wisdom’s outboard DSP, the S55i’s low end is shaped to the system’s target curve for consistent results across different rooms and mounting positions.
Type: in-wall subwoofer, Regenerative Transmission Line. Drivers: 4 × 3 × 5-inch long-throw woofers. Frequency response: 40 Hz–80 Hz (±3 dB to target). Sensitivity: 90 dB/2.83 V/1 m. Maximum SPL: 112 dB at 40 Hz/1 m. Impedance: 8 ohms. Requires DSP and one amplifier channel per subwoofer. Dimensions: 54 × 15.875 × 4.25 inches. Weight: 43 lb.
The S55i is for the installation where low frequencies need to be felt but the subwoofer must not be seen — a dedicated cinema, a media room, or a high-end living space with an architectural speaker system. It is part of a designed, processor-driven system rather than a standalone box.
In-wall subwoofers depend on correct loading, placement and calibration to deliver clean, even bass. We specify, install and calibrate Wisdom systems as a whole — subwoofer, processor and amplification — across the South. Please enquire to discuss your room and how best to integrate it.
