Wisdom In Wall S57i Subwoofer
POA
The Wisdom Audio S57i is an in-wall transmission-line subwoofer that fits a standard stud bay, yet reaches down to 25Hz — concealed bass with the speed and articulation of the finest freestanding designs.
Description
Description
Overview
The S57i is Wisdom Audio’s in-wall transmission-line subwoofer, engineered to deliver deep, articulate bass from within a standard wall or ceiling. Part of a custom-install-focused range, it offers the kind of low-frequency performance normally associated with large freestanding subwoofers, but disappears into the building fabric.
Design & build
The S57i mounts in-wall or in-ceiling within a 2×4 stud bay at just over four inches deep, fitting behind 1/2-inch or 5/8-inch drywall. Its transmission-line enclosure is folded to fit the cavity while loading a single 10-inch high-operating woofer. At around 40 lb it is comparatively light for a subwoofer, easing installation into new-build or retrofit walls.
Performance
The transmission-line design gives depth, dynamics and low distortion, with a quoted flat response across a 25Hz–130Hz operating range (25Hz–130Hz ±3dB, −10dB at 22Hz) and a maximum SPL of 108dB at 1m. The result is fast, tonally accurate bass that integrates seamlessly with high-resolution main speakers rather than simply adding weight.
Key features
A single 10-inch high-operating woofer in a folded transmission line. Fits a standard 2×4 stud bay, in-wall or in-ceiling. Requires DSP and one channel of power amplification per subwoofer for correct operation. Designed to partner Wisdom’s Insight and Sage series speakers for a fully concealed, high-performance system.
Technology
A transmission line loads the rear of the driver through a long, tuned path, extending low-frequency output while keeping the driver well controlled — giving high sensitivity, high output and low distortion in a shallow enclosure. Paired with the required DSP and amplification, the S57i is tuned to blend with the speed of planar and high-resolution main channels.
Specifications
Type: in-wall / in-ceiling transmission-line subwoofer (2×4). Driver: one 10-inch high-operating woofer. Frequency response: 25Hz–130Hz ±3dB (−10dB at 22Hz). Maximum SPL: 108dB at 1m. Power handling: 500W peak. Impedance: 8 ohms. Sensitivity: 84dB (2.83V, 1m). Requirements: DSP and one channel of amplification per subwoofer. Dimensions: 53.27 × 16 × 4.13 in (H × W × D). Weight: 40 lb (18 kg).
Who it’s for
The S57i is for the media room or dedicated cinema where bass must be felt but not seen — where architectural, in-wall subwoofers are needed to keep the room clean while still integrating with high-resolution speakers. It suits new-build and retrofit installations alike.
Why buy from Hidden Home Technology
In-wall subwoofers depend entirely on correct DSP, amplification and room integration to perform. We design and install dedicated cinemas and media rooms across the South, calibrating Wisdom Audio bass into the room as a whole. Pricing is on application — speak to our team to discuss your project.
The Hidden Home view: Wisdom S57i
The S57i is a transmission line subwoofer made to go into a wall or a ceiling, so a room can have deep bass with no box on the floor. Wisdom quotes a response down to 25 Hz from its single 10 inch woofer.
It needs only 105 mm of depth inside the wall and stands 1.35 metres tall behind its grille. Each one needs DSP and its own channel of amplification, and Wisdom rates its maximum output at 108 dB at one metre.
It suits a cinema or a living room where the bass must be hidden as completely as the speakers. Where a room needs more depth and output the larger S90i fits a deeper wall. We work out where they go and tune them with the rest of the system, so call us.
Sources: Wisdom Audio, “S57i”, the maker’s own page.
Specification
Impedance 8 ohms
Sensitivity 84 dB / 2.83 V / 1m
Power Handling, Peak 500w
Maximum SPL 108dB / 1m
Product Weight 40 lbs. (18 kg)
Shipping Weight 48 lbs. (22 kg)
Dimensions – HxWxD 53.27” x 16” x 4.13” (1353mm x 406mm x 105mm)
